Yamaha TT-S303 Turntable
- Todds approved
- FREE SHIPPING
Let the good times roll
Iconic Sound
Turn your listening experience on its head. This turntable design has undergone rigorous tests to ensure the most faithful reproduction of sound - the way music was made to be heard.
Built-in Pre-amp
Head-spinning simplicity. Designed with a built-in phono EQ amplifier, you have the option of connecting to a line input on an amp without a phono stage, or even to active speakers!
Alternatively, if you want to utilise the phono stage of your amplifier, switch the TT-S303 to phono output mode for the perfect pairing with your favourite amp.
Trademark Sound
There's nothing like the nostalgic sound of vinyl to connect you with the music.
Experts in sound, Yamaha boasts an enviable back-catalogue of Hi-Fi products that have shaped the way we listen to music. Some products have gone on to achieve iconic and even legendary status in Hi-Fi circles - touted for their quality, innovation and trademark Yamaha sound.
The TT-S303 signals a return of the Yamaha turntable - drawing inspiration and expertise from the company's unsurpassed musical roots.
Designed for Hi-Fi
The TT-S303 was designed to match the classic look and aesthetic of Hi-Fi components.
Whether paired with a stereo amp or receiver, add a turntable to your setup to enjoy both classic and modern vinyl collections.
| Turntable | Drive Method | Belt drive |
|---|---|---|
| Motor | DC motor | |
| Rotation Speed | 33-1/3 rpm, 45 rpm | |
| Rotation Speed Variation | ±2% | |
| Wow And Flutter | 0.2% | |
| Platter | Aluminium die-cast (Diameter 30 cm) | |
| Output Level | 140 mV (-17 dBV, with RIAA EQ), 2.5 mV ± 3 dBV (without RIAA EQ, 1 kHz, 3.54 cm / sec) | |
| Signal To Noise Ratio | 67 dB or higher (A-weighted, 20 kHz, LPF) | |
| Tonearm | Tonearm | Static balance straight tonearm |
| Effective Arm Length | 223.5 mm | |
| Overhang | 19 mm | |
| Stylus Pressure Adjustment Range | 0-4 g | |
| Acceptable Cartridge Weight | 15.5-19 g (including headshell) | |
| Attached Cartridge | Cartridge Type | MM type |
| Output Voltage | 2.5 mV (1 kHz, 3.54 cm / sec) | |
| Stylus Pressure | 3.5 ± 0.5 g | |
| Cartridge Weight | 5.0 ± 0.3 g | |
| Cartridge Height | 17.0 ± 0.7 mm | |
| Head-shell Weight | 10 g (including screws, nuts and wires) | |
| Audio Specifications | Output Terminal | RCA: 1 (PHONO) |
| General | Power Consumption | 1.5 W |
| Standby Power Consumption | 0.1 W | |
| Dimension (W×H×D) | 450 x 136 x 368 mm; 17-3/4” x 5-3/8” x 14-1/2” | |
| Weight | 4.8 kg; 10.6 lbs. |
